Basic Parameters:
Contact Capacity: 220V / 0.7A
Switch Voltage: 24VDC / 220VAC
Connecting Flange: None
Insulation Resistance: ＞ 100m Ω
Thread Size: M16 * 2 * 50mm
Material: SUS316
Output Signal: switching value (four wire)
Working Temperature: -20~100℃
Working Pressure: 0 ~ 1.0MPa
Medium specific gravity: ＞ 0.55
Model Selection
|
L-MQK |
-A- |
-R |
-C |
|
Temperature transmitter module |
Installation |
Relay outputs |
Material |
|
|
1: Flange (e.g. A1-DN50, A1-2”) 2: Thread (e.g. A2-1”BSP, A2-M27*2) |
1：1 realy 2：2 realys 3：3 realys 4：4 realys 5：5 realys
|
4: 304 SS 6: 316SS 1: PTFE 0: Specified
|
