Model MC20B Universal Pressure Transmitter

Price: US$58.00
Product description:
DOWNLOAD DATA SHEET
INQUIRY

DESCRIPTION：

MC20B Universal Pressure Transmitter is a cost efficient general purpose pressure transmitter. Each unit is constructed of stainless steel for durability in severe environments. Both gas and liquid pressure overloads of up to 200% over capacity are safely accepted.

The transmitter uses proprietary current output with wide temperature compensation. This design references the primary pressure sensing diaphragm to the atmosphere, and provides a stable zero regardless of the transducer environment.

FEATURES：

Pressure Media	Fluids, gas
Supply Voltage	12 to 36V
Operating Range	Gauge Pressure: Max(0～100)MPa, Min(0～0.1)KPa Absolute Pressure: Max(0～100)MPa, Min(0～20)KPa(0.5%)/(0～60 & above)KPa(0.25%)
Operating Range	(Negative Pressure)---Max(-100KPa～), Min(-0.1～0.1)KPa
Accuracy	±0.25%, ±0.5%(25℃)
Over Pressure	200% full scale
Long Term Stability	<0.25%FS per year
Response	<100ms
Output Signal	(4～20)mA（Current two-wire/three-wire）,（0～10/20）mA （0～5）V,（1～5）V,（0～10）V, etc.
Temperature Range	-20～85℃(Normal), -20～200℃(Installation of the radiator)
Temperature Effects	0.00015%FS/℃
Pressure Connection	G1/2 female or user specified
Electrical Connection	Waterproof Connector(M20*1.5)
Protection Class	IP65

ORDERING CODES：

MC20B( KPa)口口E口A口C口R口 Universal pressure transmitter
	(KPa )	Operating Range
		G: Gage Pressure A: Absolute Pressure P: Negative Pressure
			K: Diffused silicon transducer T: Ceramic piezoresistive transducer P :Ceramic capacitor transducer
			E口	Output Signal
				1：(0～5)VDC 2：(4～20)mA 3： User Specified
				A口	Accuracy
					1：0.25 2：0.5
					C口	Pressure Connection
						1：G1/2 female 2：User Specified
